Grade 12 Titanium `Titanium Grade 12 Stockist UNS R53400
WERKSTOFF NR. 3.7105 Titanium Gr12 Products, Titanium Grade 12 Composition
Titanium Grade 12 Price Per Kg, Grade 12 Titanium Exporter In Mumbai, India
Titanium Grade 12 Price Per Kg, Grade 12 Titanium Exporter In Mumbai, India
Titanium Grade 12 Composition
Titanium Grade 12 Specification
| Grade | Ti | C | Fe | H | N | O | Al | V |
|---|---|---|---|---|---|---|---|---|
| Ti Grade12 | 90 min | – | 0.25 max | – | – | 0.2 max | 6 min | 4 min |
Titanium Gr 12 Mechanical & Physical Properties
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| Ti Gr 12 | 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 | Psi – 128000 , MPa – 880 | 14 % |
| Common Name | |
|---|---|
| Titanium Grade 12 | |
| Ti-CODE 12™ | |
| Ti-0.3Mo-0.8Ni | |
| UNS | |
| R53400 |
| Minimum Tensile Properties | ||||
|---|---|---|---|---|
| Condition | UTS ksi (Mpa) | >0.2%YS ksi (MPA) | % El. | % RA* |
| As specified (shape) | 70 (483) | 50 (345) | 18 | 25 |
| Typical Tensile Properties | ||||
|---|---|---|---|---|
| Condition | UTS ksi (Mpa) | >0.2%YS ksi (MPA) | % El. | % RA* |
| As provided | 88 (607) | 67 (462) | 22 | – |
Titanium Grade 12 Melting Point
| Melting point | 1670°C, 3038°F, 1943 K |
| Boiling point | 3287°C, 5949°F, 3560 K |
| Density (g cm−3) | 4.506 |
Titanium Grade 12 Equivalent
| STANDARD | WERKSTOFF NR. | UNS |
|---|---|---|
| Titanium Gr12 | 3.7105 | R53400 |
Titanium Grade 11 Suppliers, Titanium Alloy Grade 11
Titanium Grade 11 Pipe
Titanium Grade 11 Tube
Titanium Grade 11 Tubing
Steel Alloys Titanium Grade 12 is an advanced titanium alloy, enhanced with 0.3% molybdenum (Mo) and 0.8% nickel (Ni). This alloy offers superior corrosion resistance in both reducing and oxidizing environments, making it ideal for chemical and marine applications. It excels in high-temperature applications, such as shell and tube heat exchangers, and is known for its excellent weldability and resistance to crevice corrosion.
Grade 12 titanium features a near-alpha microstructure with acicular alpha and small amounts of beta phase. Its Beta Transus temperature is approximately 1634°F, contributing to its strength and formability. Commonly used in chemical manufacturing, marine, and aerospace industries, this alloy performs well in mildly reducing or variable oxidizing-reducing media. Heat treatment of this alloy enhances its corrosion resistance, offering a cost-effective alternative to palladium. For machining, tungsten carbide or cobalt high-speed tools are recommended.
